Open-type cold room unit is the ordinary type cold room unit. It is widely used in all kinds of cold storage. CBFI has engaged in cold storage design, manufacture, and construction for over 10 years. It is able to provide you not only the machine unit, but also the one-stop cold storage solution.
◪ Convenient maintenance.
◪ Rational structure, making full use of the heat exchange capacity of the condenser.
◪ High quality refrigeration components and completed configuration, ensuring great unit operational reliability.
◪ Adopting Bitzer semi-hermetic refrigeration compressors, for high energy efficiency ratio and low noise.
◪ Adopting efficient shell tube condensers, assuring high heat exchange efficiency and long service life.
◪ Convenient wiring. The Bitzer water cooling unit is equipped with waterproof terminal boxes. And all control component connection will access the junction box.
There are three kinds of surface material for chosen, stainless steel, aluminium plate and color steel. The characters of the three plates are different. Our design engineer provide different solutions for different requirements. The thickness of the plate could be customized. We also provide normal standard.
Bitzer Air-condensing Cold Room Unit
This unit is using Germany Bitzer piston compressor. It has a strong power and good quality.
Bitzer Screw Compressor Cold Room Unit
Bitzer screw compressor can be used at various temperatures, has stronger environmental adaptability. It is more energy efficient when it achieves the same cooling capacity. Its price is even higher.
Copeland Paralleled Cold Room Unit
Copeland is from US, the quality is also good. The paralleled system is able to operate when one of the compressors is not working. This allows the cold storage running without goods loss.
Bitzer Paralleled Cold Room Unit
This unit combines the good quality of Bitzer and stable operation of paralleled system. It is high efficient, stable and reliable.
Open Compressor Cold Room Unit
This kind of compressor is suitable for vibrating environment. In other words, it is always used on ship.
Copeland Scroll Cold Room Unit
Scroll compressor is more stable. The power is limited, but it is already suitable for small cold room.
Bristol Compressor Models
1,H2BG094,H2BG104,H2BG124,H25G144,H2NG184,H2NG204,H2NG244,H2NG294
2, Low price
3,Original:US
Bristol Piston Air Compressor
Advantages
1)Environmentally friendly
2)Smaller piston bristol compressor dimensions or smaller displacements possible
3)Low noise level, innovative piston bristol compressor technology
4)Compact start equipment
5)Low energy consumption
6)High thermal working conditions
7)High product quality
8)Wide voltage range
Specifications:
Model | Capacity | Input Power(W) | EER/COP | Electrical data | Exhaust volume | Refrigeration oil(L) | Weight | Height | |||
BTU/H | WATTS | BTU/H | RLA | LRA | MCC | CC/REV | KG | MM | |||
H2BG094DBE | 72400 | 21244 | 7020 | 10.3 | 12 | 72 | 18 | 167.46 | 2.84 | 63 | 447 |
H2BG104DBE | 84390 | 24762 | 8155 | 10.4 | 14.2 | 77 | 20.2 | 190.57 | 2.84 | 70 | 467 |
H2BG124DBE | 97000 | 28462 | 9790 | 9.9 | 16.5 | 80 | 25 | 219.57 | 2.84 | 71 | 467 |
H2BG144DBE | 116667 | 34233 | 11550 | 10.1 | 21.6 | 126 | 34.5 | 246.56 | 2.84 | 80 | 531 |
H2NG184DPE | 147200 | 43192 | 14250 | 10.3 | 26 | 125 | 40 | 334.93 | 6.62 | 115 | 567 |
H2NG204DRE | 173680 | 50961 | 16770 | 10.4 | 30 | 150 | 49 | 381.14 | 6.62 | 118 | 567 |
H2NG244DPE | 199850 | 58640 | 20220 | 9.9 | 36.5 | 190 | 56 | 439.14 | 6.62 | 125 | 567 |
H2NG294DPE | 238000 | 69834 | 25300 | 9.4 | 44 | 215 | 69 | 508.29 | |||
Technical Data sheet:
Drawing:
Pictures:
