CBFI BF10000 10 Tons Per Day Seawater Type Flake Ice Machine
10 tons 24 hrs flake ice machine BF10000 is widely used in seaport for fish cooling. The seawater type flake ice machine is using anti-corrosion material for evaporator. So it is able to use seawater as water source for ice making. We have built several auto flake ice projects in many countries. The systems are consist of containerized flake ice machine, cold storage with raking system, auto ice weighing system. Click here to check one of the projects 40 Tons Per Day Automatic Flake Ice System, Mozambique
Main Features
● Daily Capacity: 10 ton 24 hrs
● Machine power supply: 3 phase industrial power supply
● Control system is using Siemens PLC and touch screen, it is very easy to use.
● Evaporator and ice cutter are made of high quality material, the lifespan is ensured.
● We provide the seawater type ice machine, which is able to use seawater to make ice.
● Auto flake ice system available by using ice storage with rake.
● The ice temperature is as low as -8 ℃.
● Flake ice is dry, the edge of ice is not sharp, it is good for direct cooling of food
● Flake Ice is thin, it has excellent cooling performance
● Flake ice is 1~2 mm thickness
Dye-chemistry industry,
large concrete project,
large crude and fresh supermarket,
meat process,
large fishery wholesale market,
food processing company and more
| Flake Ice Machine Parameters | |||||||
| Model | Daily output (T/24h) | Cooling Method | Compressor Power | Fan Power for Cooling Tower | Cooling Pump Power | Unit size (L*W*H mm) | Unit N.W. (kg) |
| BF500 | 0.5 | Air | 4.1kw | — | — | 1280*800*800 | 160 |
| BF1000 | 1 | Air | 7.44kw | — | — | 1320*900*900 | 210 |
| BF2000 | 2 | Air | 10kw | — | — | 1750*1100*1050 | 360 |
| BF3000 | 3 | Water | 8.45kw | 0.37kw | 1.5kw | 1500*1250*1260 | 1000 |
| BF5000 | 5 | Water | 13.49kw | 0.75kw | 2.2kw | 1900*1500*1470 | 1100 |
| BF6000 | 6 | Water | 19.94kw | 0.75kw | 2.2kw | 1900*1500*1470 | 1100 |
| BF8000 | 8 | Water | 24.2kw | 1.5kw | 2.2kw | 2400*1900*1860 | 1300 |
| BF10000 | 10 | Water | 33.8kw | 1.5kw | 4kw | 2500*2000*1860 | 1500 |
| BF15000 | 15 | Water | 44.5kw | 1.5kw | 4kw | 3350*2150*1960 | 3200 |
| BF20000 | 20 | Water | 64kw | 1.5kw | 5.5kw | 3400*2220*2230 | 4200 |
| BF25000 | 25 | Water | 76.5kw | 2.2kw | 5.5kw | 3700*2250*2510 | 4600 |
| BF30000 | 30 | Water | 93.7kw | 2.2kw | 7.5kw | 4700*2250*2520 | 5000 |
| BF40000 | 40 | Water | 118kw | 2.2kw | 7.5kw | 5000*2300*2700 | 7500 |
| ♦ Compressor Brand: Bitzer / Hanbell; Refrigerant: R22/R404A; ♦ Power Supply: Voltage 380V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately). ♦ Operating Conditions: T(water supply) : 20 ° C, T(ambient) : 32 ° C, T(condensing) : 38 ° C,T(evaporating)：-20℃. ♦ (Note: The actual ice production varies due to the influence of water supply temperature and ambient temperature.) ♦ (The final interpretation of the above metioned parameters is in Icesource, there will be no further notice, if there is any technical change.) | |||||||
To evaluate the efficiency and stability we use screw type compressor on large capacity ice machines.
We provide auto ice storage with ice raking system for large capacity flake ice machine. This system allows the machine to operate 24 hrs a day, 7 days a week. When the ice storage is full, the system will stop the ice machine automatically.
Air Cooled Industrial Ice Flake Machine 10T
Introduction:
Our Heavy Duty Industrial Flake Ice Machine capacity is from 0.5T to 25T per day,
with Bitzer Compressor and schneider electric parts, the machine get high performance.
the ice drum inside surface is food grade SS304, corrision-ressitent
PLC automatic controlled, lack of water alert, pressure alert, full of ice alert, phrase protector, overload alert
High reliability, low failure & maintenance .
Specifications
1. Capacity : 1 to 25T
2. Bitzer Compressor , Schneider electric parts and Danfoss Refrigeration parts
3, Water Cooled / Air Cooled
5. Envrioment friendly Refrigerant R22/R404a
6. SS304 Inside surface in ice drum.
7. long service life and high reliability
feel free to contact us if you have any idea: sky-pe:refriend1018.
Model | LT-5000W | LT-8000W | LT-10000W | LT-12000W | LT-15000W | LT-20000W | LT-25000W | |
Daily output | 5 | 8 | 10 | 12 | 15 | 20 | 25 | |
Ambient Temp. | +32°C | |||||||
Water Temp. | +20°C | |||||||
Cooling capacity (KW) | 32 | 52 | 65 | 78 | 98 | 130 | 165 | |
Compressor brand | Bitzer | Bitzer / Hanebll | ||||||
Refrigerant | R404A / R22 | |||||||
Running power(KWH) | 20 | 30 | 38 | 48 | 62 | 75 | 98 | |
Install power(KW) | 30 | 40 | 45 | 55 | 70 | 90 | 120 | |
Power | 380V/3P/50Hz | |||||||
Cooling Type | "A” — air cooling ;"W" — water cooling | |||||||
Dimension | Length | 1900 | 2600 | 2600 | 2600 | 3000 | 3200 | 3200 |
Width | 1400 | 1600 | 1600 | 1600 | 2000 | 2000 | 2000 | |
Height | 1450 | 1550 | 1750 | 1950 | 1950 | 2200 | 2550 | |
Weight(kg) | 1150 | 1650 | 2100 | 2350 | 2800 | 3400 | 3800 | |
a) Cooling capacity is based on evaporating temperature at -15°C,condensing temperature at +38°C; | ||||||||
Note: Model and specifications can be subject to change without notice. | ||||||||
Ice Flake Evaporator 0.3t/24hrs
As the key part of the complete flake ice machine, the ice flaker evaporator plays important
role in making ice. To match the various Ice flaker evaporators, you can make different choice
about the refrigeration units in different refrigerant (R22, R404A) by yourselves
before place the order, let me know which refrigerant you'll choose.
Flake Ice Evaporators Characteristics:
→The ice flaker evaporator processed from special alloy with lightness and high heat
conduction efficient approximating that of Aluminum.
→Every flake ice scraper processed in special designing without any jointing then in
high solidity and can rotate well nearly 8 years.
→All components selected is of top-quality and meet configuration need, which makes.
the evaporator hold less space, and achieve best performance.
→The flake ice is glittering and translucent, hard and pure.
→Ice making and dropping in high speed.
